1. Adopt 6-ton articulated fixed structure universal chassis.
2. Double cylinder hydraulic steering, four-wheel drive, small turning radius.
3. The front frame is equipped with a swing frame, which increases the swing angle of the front and rear bodies in the vertical plane, so that the whole vehicle can land on all wheels on muddy and pothole roads, and more effectively improve the adhesion performance of the wheels and the vehicle's passability.
4. The power system adopts Cummins water-cooled engine, which has low noise and long life.
5. The transmission system adopts a domestic well-known brand power shift gearbox and front and rear drive axles that integrate torque converter and gearbox. It is reliable to use and has strong climbing ability.
6. The cab adopts ergonomic design, has ROPS/FOPS certificate, and is equipped with heating and cooling air conditioners, which improves driving comfort and safety.
7. The main components of the hydraulic system adopt imported brand products to ensure the reliability of the hydraulic system.
8. The braking system adopts a dual-circuit hydraulic braking system, using products from the world-renowned Italian brand SAFIM; the working brake is a fully enclosed wet multi-disc hydraulic brake, and the emergency brake and parking brake are hydraulically released spring brakes, which effectively ensure braking safety.
9. In order to effectively ensure low pollutant emissions, the National IV engine is used to make the exhaust emissions meet the national emission standards, and the exhaust noise is greatly reduced.
10. The frame adopts post-weld annealing and shot blasting treatment to eliminate welding stress and ensure the quality of the whole machine.
11. The cab is equipped with an on-board computer system, which can display the engine status and protection information, driving speed information, and fault information in real time to ensure the safe operation of the vehicle.
12. The vehicle is equipped with a reversing image system that can record and store relevant information.
13. The tank body adopts an inclined design, which is conducive to fully mixing concrete while preventing leakage of materials and slurry during uphill transportation; the feeding and discharging device is designed at the tail of the tank body, and the hatch is closed with the company's patented hydraulic valve, which does not require manual opening of the loading and unloading port, which is more convenient, time-saving and labor-saving.
14. Optional water metering device, combined with the mixing drum made of high-quality wear-resistant and high-strength steel plates, customized spiral blades in the tank and special chutes, can realize the function of mixing dry materials into the tank, adding water, mixing and rotating to produce concrete under special circumstances, providing more flexible and convenient processing methods for production.
15. Vehicle cleaning: hydraulically driven high-pressure cleaning water pump; feeding and discharging method: hydraulic control method is adopted, automatic feeding and discharging.
